| Place of Origin | Hebei,China |
| Certification | ISO9001 |
4-3/4" (120mm) Even Wall Down Hole Motor for Oil and Gas Well Directional Drilling
Local aging of elastomer occurs frequently in conventional downhole motors because the elastomer thickness of conventional downhole motor is different. The elastomer are worn not evenly. That leads to a power section failure soon. This problem is solved greatly in Even Wall Thickness downhole motors. The elastomer of even wall thickness downhole motor is the same. It is worn evenly in drilling operation so it extends the working life greatly. Even wall thickness downhole motors also provide 50% more toque than conventional downhole motors and longer working life in directional well drilling.
Our ET Series downhole motor are able to be custom made as per the customers detailed requirements if the required size is not available in below tables.
Availability of our small size downhole motor:
| Downhole Motor Specification | OD | Bit Size | Connection | Lobe | Stage | Flow Rate | RPM | Working Pressure Drop | Output Toque | Max Pressure Drop | Max Toque | Operating WOB | Max WOB | Output Power | |||||||||||
| mm | In | mm | In | Top | Bottom | Lpm | Gpm | MPa | Psi | N.m | lb-ft | MPa | Psi | N.m | lb-ft | kN | lb | kN | lb | KW | HP | ||||
| 5LZ-120-4.2-890 | 120 | 4-3/4 | 149~200 | 5-7/8~7-7/8 | 3-1/2REG | 3-1/2REG | 5:6 | 4.2 | 380-950 | 100-251 | 72-181 | 9.76 | 1416 | 5288 | 3900 | 14.64 | 2124 | 7932 | 5851 | 50 | 11240 | 80 | 17600 | 100 | 134 |
| 7LZ-120-3.8-1150 | 120 | 4-3/4 | 149~200 | 5-7/8~7-7/8 | 3-1/2REG | 3-1/2REG | 7:8 | 3.8 | 570-132 | 151-349 | 77-178 | 8.83 | 1281 | 5371 | 3962 | 13.25 | 1921 | 8057 | 5943 | 50 | 11240 | 80 | 17600 | 100 | 134 |
